VSA-E07
2
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
CONTRAST TABLE
Part No.
Ref. No. Mark Symbol and Description VSX-908RDS-G VSA-E07 VSA-E07 Remarks
/HY /HY /HV
PCB ASSEMBLIES
NSP MAIN ASSY AWK7528 AWK7508 AWK7508
P5- 5 MAIN CONTROL ASSY AWX7410 AWX7340 AWX7340
P5-12 VIDEO ASSY AWX7422 AWX7419 AWX7419
P5-13 S-VIDEO ASSY AWX7395 AWX7308 AWX7308
P5-16 DIGITAL-I/O ASSY AWX7396 AWX7315 AWX7315
NSP COMPLEX ASSY AWK7529 AWK7509 AWK7556
P5- 2 EXTERNAL IN (EXTRA-5.1) ASSY AWX7413 AWX7348 AWX7348
P5- 3 A-PINJACK ASSY AWX7412 AWX7346 AWX7346
P5- 4 CONNECTION ASSY AWX7347 AWX7558 AWX7558
P5- 9 REGULATOR ASSY AWX7310 AWX7559 AWX7559
P5-11 TRANS 2-2 ASSY AWX7518 AWX7470 AWX7470
P5-15 PRIMARY ASSY AWX7345 AWX7345 AWX7454
NSP FRONT/VAMP ASSY AWK7530 AWK7511 AWK7511
P5-19 V-AMP ASSY AWX7309 AWX7514 AWX7514
P8- 2 DISPLAY ASSY AWX7414 AWX7361 AWX7361
P8- 3 NSP ROTARY ENCODER ASSY AWX7405 AWX7328 AWX7328
VOLUME ASSY Not used AWX7367 AWX7367 No. 1
PACKING SECTION
P3- 1 AM Loop Antenna ATB7009 Not used Not used
P3- 2 FM Wire Antenna ADH7010 Not used Not used
P3- 3 Operating Instructions (English) ARB7187 ARB7189 ARB7189
P3- 4 Remote Control Unit (CU-VSX165) AXD7236 Not used Not used
P3- 4 Remote Control Unit (CU-VSA032) Not used AXD7217 *1 AXD7217 *1
P3- 9 Packing Case AHD7815 AHD7813 AHD7813
P3-14 Operating Instructions (German) ARC7244 ARC7271 Not used
P3-15 Operating Instructions (French) ARC7245 ARC7247 Not used
P3-16 Operating Instructions (Italian) ARC7246 ARC7248 Not used
P3-17 Operating Instructions (Dutch) ARC7270 ARC7249 Not used
P3-18 Operating Instructions (Swedish) ARC7280 ARC7283 Not used
P3-19 Operating Instructions (Spanish) ARC7281 ARC7284 Not used
P3-20 Operating Instructions (Portuguese) ARC7282 ARC7285 Not used
Remo-con. Cushion Not used AXG7080 AXG7080 Accessories
VSA-E07/HY, HV and VSX-908RDS-G/HY are constructed the same except for the following :
*1 : Refer to “4. REMOTE CONTROL UNIT”.
