Pioneer VSA-E07 - Rotary Encoder Assembly Contrast; Primary Assembly Contrast; Digital I;O Assembly Contrast; Volume Assembly PCB Parts List

VSA-E07
8
PCB PARTS LIST
Mark No. Description Part No.
VOLUME ASSY
SEMICONDUCTORS
Q7301, Q7302 2SA1993
Q7303, Q7304 2SC5395
D7301 1SR154-400
CAPACITORS
C7301 CEANP100M16
C7302 CEAT220M50
C7303 CEAT471M6R3
RESISTORS
VR7301 (VARIABLE WITH MOTOR) ACX7037
Other Resistors RS1/10S J
OTHERS
CN7301 8P FFC CONNECTOR 52045-0845
KN7301 EARTH METAL FITTING VNF1084
F
Z
AWX7328 and AWX7405 are constructed the same except for the following :
ROTARY ENCODER ASSY
F
T
Mark Symbol and Description
Part No.
Remarks
AWX7405 AWX7328
C7103, C7104 CKSQYB103K50 Not used
R7103, R7104 RS1/10S103J Not used
S7101 ASX7004 Not used
AWX7454 and AWX7345 are constructed the same except for the following :
PRIMARY ASSY
F
V
Mark Symbol and Description
Part No.
Remarks
AWX7345 AWX7454
Y6003 AWG18 BOARD IN ADX7321 Not used
Y6004 AWG18 BOARD IN ADX7320 Not used
Y6005 AWG18 BOARD IN ADX7319 Not used
AWX7315 and AWX7396 are constructed the same except for the following :
DIGITAL I/O ASSY
F
W
Mark Symbol and Description
Part No.
Remarks
AWX7396 AWX7315
JA1204 2P PIN JACK AKB7095 AKB7121
