VSA-E07
7
AWX7419 and AWX7422 are constructed the same except for the following :
VIDEO ASSY
F
P
Mark Symbol and Description
Part No.
Remarks
AWX7422 AWX7419
702, 705 2P RCA PIN JACK AKB7017 AKB7076
706 2P RCA PIN JACK AKB7017 Not used
707 1P RCA PIN JACK AKB7020 Not used
JA701 3P PIN JACK (For 706 and 707) Not used AKB7109
AWX7308 and AWX7395 are constructed the same except for the following :
S-VIDEO ASSY
F
Q
Mark Symbol and Description
Part No.
Remarks
AWX7395 AWX7308
CN801 4P MINI DIN SOCKET AKP7043 Not used
CN802, CN803 4P MINI DIN SOCKET AKP7020 AKP7023
JA801 4P MINI DIN SOCKET (For CN801) Not used AKP7049
AWX7361 and AWX7414 are constructed the same except for the following :
DISPLAY ASSY
F
S
Mark Symbol and Description
Part No.
Remarks
AWX7414 AWX7361
IC7071 Not used M66311FP
IC7401 BU1923 Not used
Q7002 DTC124EK Not used
Q7401 2SA1993 Not used
Q7402 DTC143ES Not used
Q7403 2SC1740S Not used
D7002 SLR-343VR Not used
D7071–D7079 Not used SLR-343VR(MNP)
L7401 LFA2R2J Not used
S7022, S7024–S7028, S7030 VSG1009 Not used
C7011, C7073, C7074 Not used CKSQYB102K50
C7071 Not used CEAL101M6R3
C7072 Not used CKSQYB473K50
C7401 CKSQYB472K50 Not used
C7402 CEAT2R2M50 Not used
C7091, C7403, C7404 CKSQYB102K50 Not used
C7405 CEAT101M10 Not used
C7406, C7407 CCSQCH270J50 Not used
C7408 CKSQYB561K50 Not used
C7409 CEAT1R0M50 Not used
R7038 RS1/10S271J Not used
R7047, R7048 RS1/10S223J Not used
R7071–R7079 Not used RS1/10S271J
R7080–R7083 Not used RS1/10S102J
R7092 Not used RS1/10S473J
R7401, S7407, S7408 RS1/10S102J Not used
R7403 RS1/10S222J Not used
R7404 RS1/10S473J Not used
R7405 RS1/10S333J Not used
R7406 RS1/10S104J Not used
CN7003 Not used 52045-0845
X7401 CRYSTAL RESONATOR (4.332MHz) ASS7004 Not used
PCB BINDER Not used VEF1040
To Next Page
