VSA-E07
6
AWX7340 and AWX7410 are constructed the same except for the following :
MAIN CONTROL ASSY
F
D
Mark Symbol and Description
Part No.
Remarks
AWX7410 AWX7340
IC103, IC105 NJM4558MD UPC4570G2
Q991 2SC1740S Not used
Q992 2SC2412K Not used
D991 1SS355 Not used
D995 UDZ11B Not used
C109, C110 Not used CCSQCH221J50
C991 CEAT101M16 Not used
C992 CKSQYF225Z16 Not used
C995 CKSQYB103K50 Not used
R143, R144 Not used RS1/10S331J
R921 RS1/10S103J Not used
R922 Not used RS1/10S103J
R975, R976, R978, R980–R983 RS1/10S102J Not used
R991 RS1/10S471J Not used
R992 RS1/10S221J Not used
R993 RS1/10S101J Not used
R994 RS1/10S472J Not used
R996 RS1/10S0R0J Not used
CN902 13P FFC CONNECTOR 52044-1345 Not used
CN941 4P PIN JACK AKB7015 Not used
JA911 2P PIN JACK DKB1045 Not used
113 6P PIN JACK AKB7089 Not used
JA901, JA911 4P PIN JACK Not used AKB7075
103 6P PIN JACK (For 113) Not used AKB7088
NSP J101 Not used DB916NS0
J102 Not used DB216NS0
AWX7559 and AWX7310 are constructed the same except for the following :
REGULATOR ASSY
F
M
Mark Symbol and Description
Part No.
Remarks
AWX7310 AWX7559
IC5003 NJM78M12FA Not used
D5009 D3SBA20(B) LN4SB60-4003
C5007 CEAT472M16 CEAT103M16
C5012 CKCYF103Z50 Not used
C5013 CEAT101M25 Not used
C5019, C5021, C5023 CEAT101M10 CEAT221M10
C5029 Not used CEAT221M50
C5030 (1µF/100V) Not used ACH1237
AWX7470 and AWX7518 are constructed the same except for the following :
TRANS 2-2 ASSY
F
O
Mark Symbol and Description
Part No.
Remarks
AWX7518 AWX7470
IC5501 AEK7018 (4A) AEK7019 (5A)
C5501 CEANPR47M50 ACH1237 (1µF/100V)
R5501 RFA1/4PS100J RFA1/4PS220J
R5502 RD1/4PU104J Not used
