Pitco E7 Service, Parts And Schematics

5-6
Table 5-1 Frame-Cabinet / Electrical Assemblies With Components
Item Pitco Frialator Quantity
Number Part Number Description Per Unit
1 B7446005 Pan Liner #14 1
B7446006 Pan Liner #18 1
2 A6611401 Stop #14 1
A6611403 Stop #18 1
3 P5046980 Heater Strip 2
4 P6071448 Plug Hole 2" 1
5 A6613101 Cover, Side 1
6 A1819602 Bracket, Door Magnet 1
7 P6071300 Magnet 1
8 B3900101 Leg Set 1
9 B7402238 Bracket, Circuit Breaker 1
10 PP10104 Circuit Breaker 1
11 PP10082 Light, 125V Amber 1
12 PP10195 Screw, Button Head Hex 2
13 A6042801 Overlay 1
14 PP10375 Switch, Rocker 1
15 B3600202 Front Panel Weldment 1
16 B7230202 Hinge, Top Door 1
17 B2301208 Door #14 1
B2301210 Door #18 1
18 P6071516 Handle, Door 1
19 B7230302 Hinge, Bottom Door 1
20 P0075200 Screw, 2 #8 x 1/2 Self Drill 10
21 PP10686 Screw 6-32 x 1/4 2
22 PP10025 Screw 10-32 x 1/4 2
Revised 5/28/93
