Pitco E7 Service, Parts And Schematics

5-12
Table 5-4 UFM Filter, Motor / Return Assembly
Item Pitco Frialator Quantity
Number Part Number Description Per Unit
1 PP10101 Pump/Motor 1/3 HP, 115/230V, 50/60Hz 1
2 PP10106 Fitting, Elbow Male 90 .50D x .5 NPT 2
3 A6682702 Filter, Tubing Out SS 1
4 PP10731 Fitting, Elbow Male 90 .50D x .375 NPT 1
5 B6621401 Filter, Tubing Pump - Inlet Weldment 1
6 PP10039 Heat Tape, 1/2" x 79" 110V 165 Watt 1
7 PP10111 O-Ring, Viton .50ID x .688 x .094W 2
8 A6685601 Filter, Insulator O-Ring Fitting 1
9 P0062100 Screw, 1/4-20 x 3/8" Set 1
10 B6717701 Wiring, Motor Harness 1
11 PP10739 Thermostat, Snap Disc 1
12 PP10687 Screw, 6-32 x 5/16" TH Phillips ZN 2
13 P009110 Nut, Hex (KEP) 6-32 ZN 2
14 PP10738 Nut, Retaining Clip 5/16" - 18 1
15 P0144000 Nut, Hex 5/16" - 18 SST 2
16 P0115000 Screw, 5/16" - 18 x 3/4" HHC SSBB 3
Revised 5/28/93
