This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.
translated from italian
K24
9 METER CONFIGURATION
The METER feature a menu with which the user can select the main measurement unit, Quarts (Qts), Pints
(Pts), Litres (Lit), Gallons (Gal); The combination of the unit of measurement of the Partial register and
that of the Totals is predefined according to the following table:
Combination
no.
Unit of Measurement Partial
Register
Unit of Measurement Totals Register
1 Litres (L) Litres (L)
2 Gallons (Gal) Gallons (Gal)
3 Quarts (Qts) Gallons (Gal)
4 Pints (Pts) Gallons (Gal)
To choose between the 4 available combinations:
1
Wait for the METER to go to Standby
2
CAL
RESET
+
Then press the CAL and RESET keys together. Keep these pressed until the word
“UNIT” appears on the screen together with the unit of measurement set at that
time (in this example Litres / Litres )
3
Every short press of the RESET key, the various combinations of the units of mea-
surements are scrolled as shown below:
Gal
Qts
Pts
Gal
RESET
RESET
RESET
4
CALCAL
CAL
By pressing the CAL key at length, the new settings will be stored, the METER will
pass through the start cycle and will then be ready to dispense in the set units.
ATTENTION
The Reset Total and Total registers will be automatically changed to the
new unit of measurement.
NO new calibration is required after changing the Unit of Measurement.
