Advanced Programming Guide
EM-181
Copyright © 2023 Pixel Technologies Pty. Ltd
15
1.9.4 Alarm Log PINs
Up to 8 unique alarm reset pins can be programmed for use by multiple personnel.
To program any of the 8 alarm reset pins, enter the following sequence:
#
PIN
9
#
5
P
A
B
C
D
*
Table 7 - Alarm Log PIN's
To playback these settings for any of the 8 alarm log pins;
Enter the following and include the memory location of the PIN ‘P’;
1.10 Alarm Filtering
Alarm filtering is used to ensure an alarm is not raised in situations that are not necessary, for example
when the lift doors are already open. To override the alarm filter, hold down the alarm button for the
default programmed debounce period plus an additional 3 seconds (default).
Note: Applicable to Lift CAR stations only. All other intercom stations will playback the following;
“Rescue services are on-site and will attend to you shortly”
To program the settings, enter the following sequence:
#
PIN
9
#
9
A
*
Table 8 - Alarm Filtering
To playback these settings, enter the following sequence:
1.11 Alarm Filter Time
NOTE: Available in firmware version x.x.2128.0 or greater.
To adjust the default period of 3 seconds, enter the following sequence:
#
PIN
8
#
0
N
N
*
To playback these settings, enter the following sequence:
Setting
Minimum
Maximum
Default Value
P
Alarm PIN Memory Location
1
8
-
A - D
4 Digit PIN Code
0000
9999
1234
*
#
5
P
Setting
Disable
Enable
Default Value
A
Alarm Filter
0
1
1
#
9
1
*
Setting
Minimum
Maximum
Default Value
NN
Alarm Filter Time
00
99
03
Table 9 -Alarm Filter Time
*
#
8
0
