1.16 Extended Station Addressing
The system has the capability to add 8 additional stations above the standard eight.
1.16.1 Program the extended stations ID via Dipswitch
1. Set DIP switch to all off (MR)
2. Power on the station.
3. Set DIP 1,2,3 to ON
4. Set DIP 1,2,3 to OFF
5. The Yellow LED will start blinking, indicating landing
programming mode
6. You have 10s to program the new landing address,
please refer to Table 17;
7. After 10s the station will reboot and announce its new
station ID - i.e. “Spare 1" for landing station 1.
1.17 System Setup via SD Card
The EM-181 system can be configured using an SD Card.
1.17.1 Create a System Setup File
8. Create a conf181.txt file on your PC.
9. Enter any programming command you wish to program into your EM-181Mu, formatted as
follows;
NOTE: The format below, must commence with a colon, followed by the program setting.
:PPP = 123 This is mandatory and defines the PIN code for any of the commands below
:#PPP9#098745624* Set all HELP numbers to 98745624
10. Insert your SD Card into your PC
11. Ensure your SD Card is formatted to FAT16 or FAT32.
12. Create a CONFIG folder on the SD Card root directory.
13. Save your conf181.txt file in the CONFIG folder on the SD Card like follows:
a. CONFIG\conf181.txt
14. Safely remove the SD Card from your PC.
1.17.2 Updating the EM-181Mu Settings using SD card
1. Ensure your EM-181Mu is powered up and has a phone line connected.
2. The Status LED in Idle mode will blink Blue.
3. Insert the SD card into the SD card socket.
4. The programming will take up to 10 seconds to commence.
5. When the update commences the RGB Status LED will cycle through all the colours.
6. The update process this will take less than ~ 1 minute to complete.
7. Once complete the status LED will blink blue.
8. Remove SD Card.
