1.14 Station – Aux Input (IN1) Modes
1.14.1 Alarm Filter (Default)
When the IN1 contact is closed an additional 3 seconds is added to the alarm button debounce period.
NOTE: All stations can be programmed for Alarm filter.
1.14.2 SP
When a station (SL or SLX type) is set to SP Mode, the alarm filter input will operate to directly page
the CAR station acting as a “push-to-talk” intercom.
NOTE: A maximum of 7 stations can be programmed to SP mode.
1.14.3 FSAL
The Fire Service Access Level mode allows for the firefighter to initiate communication between the
activated station and the lift car station.
When activated this link takes precedence over all other functionalities.
When deactivated the system and all respective stations return to idle.
The SK (MR) station speaker will become active when FSAL is keyed ON. To enter the conversation,
press and hold the ‘I’ button to speak. The speaker will remain active until FSAL mode is keyed off.
NOTE: A maximum of 1 landing station can be programmed to FSAL mode.
To program a station mode, enter the following sequence:
Table 16 - Advanced System Settings
To playback these settings, enter the following sequence:
1.15 Reset to Factory Default
To reset programmable setting to factory default, enter the sequence below:
NOTE: This feature does not revert the Voice ID recording, Aux Input Modes & RPMS Programmed
values to the factory default.
