Advanced Programming Guide
EM-181
Copyright © 2023 Pixel Technologies Pty. Ltd
18
1.13.4 Periodic Reports
If enabled the unit is set to dial out and report its health check status back to a Remote Monitoring
System. The frequency at which the unit performs its auto-reporting is set by the sequence below:
#
PIN
2
#
7
N
N
*
Setting
Minimum (Days)
Maximum (Days)
Default Value
NN
RPMS Enable
01
30
03
Table 13 - RPMS Periodic Reports
To playback these settings, enter the following sequence:
1.13.5 Lift Breakdown Report
Input 2 (IN-2) on the EM-181Mu can be configured to send an RPMS report when triggered.
To send a report, RPMS must also be enabled.
To program the Lift Breakdown Report settings, enter the following of sequences:
#
PIN
8
#
2
2
A
A
B
*
Setting
Minimum
Maximum
Default
AA
Input Debounce Period (seconds)
01
99
03
B
N/O = 0, N/C = 1
0
1
0
Table 14 – Lift Breakdown Reports
To playback these settings, enter the following sequence:
1.13.6 Report Fail Alternating LED Indicator
NOTE: Available in firmware version x.x.2128.0 or greater.
If a report is unsuccessful the system will alternate the LEDs on stations connected to the system. The
EM-181 system is shipped to comply to EN81-28; therefore, this feature is enabled by default.
To program the settings, enter the following sequences:
#
PIN
8
#
3
0
1
A
*
Setting
Enable
Disable
Default
A
Report Fail LED Mode
0
1
0
Table 15 - Report Fail Alternating LED Indicator
To playback these settings, enter the following sequence:
#
0
7
*
*
#
8
2
2
*
#
8
3
0
1
