30 - ATR902 - User manual
Table of conguration parameters
1
Sen .
Sensor 23
2
o . ca L.
Oset Calibration 23
3
G. c a L.
Gain Calibration 23
4
u p.L. s .
Upper Limit Setpoint 23
5
d EG r.
Degree 23
6
Tu n e
Tune 23
7
s.d.tu.
Setpoint Deviation Tune 23
8
c. HY.
Command Hysteresis 24
9
P. b .
Proportional Band 24
10
t.i .
Integral Time 24
11
t.d.
Derivative Time 24
12
t. c.
Cycle Time 24
13
c. s . e.
Command State Error 24
14
ui . d .2
Visualization Display 2 24
15
de.st.
Delayed Start 24
16
sp. fu .
Special Functions 25
17
H Ld . F.
Hold Function 25
18
cy. a u .
Cycles Available 25
19
b.pr.c.
Block Programming Cycles 25
20
w.t.s.e.
Waiting Time Step End 25
21
m.G.s . e.
Max. Gap Step End 25
22
r.i . cY.
Recovery Interrupted Cycle 25
23
AL. 1
Alarm 1 26
24
a .1 . s . o .
Alarm 1 State Output 26
25
a .1 . t H .
Alarm 1 Threshold 26
26
a .1 . H y .
Alarm 1 Hysteresis 26
27
a .1 . s e .
Alarm 1 State Error 26
28
a.1.Ld.
Alarm 1 Led 26
29
a.1.a.t.
Alarm 1 Action Type 27
40
c. fLt.
Conversion Filter 27
41
s.spu.
Starting Setpoint 27
42
cHro .
Chronometer 27
43
po w . c.
Power Consumption 27
46
o . keY
On/O Key 28
47
Led.m.
Led Mode 28
48
c Y .1 . n .
Cycle 1 Name 28
