12 - ATR902 - User manual
7 Programming and conguration
There are two programming levels:
1. Cycles programming (for operator/user), to enter time/setpoint values for each
step of cycle.
2. Conguration (for manufacturer/installer of plant), to enter main parameters
(sensor type, output type, intervention type alarm/auxiliary ext.).
7.1 Programming (or modifying) cycle data
• With or without starting setpoint
• With or without timed auxiliary outputs
1
When controller is in
STo P
follow the points below.
Press Display Do
1
CYC LE
Red display visualizes
c Y . 01
At each pression selects the next
cycle (
cY.02
for cycle no.2 up to
c Y .1 5
for cycle 15).
7.1.1 Programming of starting setpoint (if not congured, see
par. 6.1.2)
The selection of an initial setpoint (a specic starting temperature of the cycle)
grants the correct gradient if the kiln is still heat from a previous process.
Press Display Do
2
STEP
Red display visualizes
00-5
*.
Green display shows the
“starting setpoint”.
Otherwise pass to point 4.
At any time press
STA RT
STOP
to exit
programming.
3
Increases, decreases value on
green display.
Select starting setpoint (starting
temperature).
1
This section includes all available options for the cycle programming. Some of these steps can be
omitted if not all the controller functions are used. We recommend the manufacturer to indicate into
the kiln documentation the correct sequence of operations.
