User manual - ATR902 - 7
Introduction
Thanks for choosing a Pixsys device.
The plug-in controller ATR902 is specially dedicated to applications in the glass,
metal and pottery industry.
This controller provides high accuracy of the programmed ring cycle and reliable
monitoring of the temperature. It can store up to 15 completely congurable
programs, each consisting of max. 18 segments. The rst 5 cycles can be associated
to a mnemonic name (see parameters 48-52). Delayed start is also available as
well as other software functions. A relay output can be congured as alarm. All
parameters are protected by a password to avoid unauthorized access.
1 Safety guide lines
Read carefully the safety guidelines and programming instructions contained in
this manual before using/connecting the device.
Disconnect power supply before proceeding to hardware settings or electrical
wirings.
Only qualied personnel should be allowed to use the device and/or service it
and in accordance to technical data and environmental conditions listed in this
manual.
Do not dispose electric tools together with household waste material.
In observance European Directive 2002/96/EC on waste electrical and electronic
equipment and its implementation in accordance with national law, electric tools
that have reached the end of their life must be collected separately and returned
to an environmentally compatible recycling facility.
2 Model identication
The ATR902 series includes only one version which is described into the following
table:
Power supply 230 Vac ±15% 50/60Hz – 3VA
ATR902-12ABC 1 sensor input + 2 relays 1A
3 Technical data
3.1 General features
Display 4 display 0,50’’ - 4 display 0,30’’ - 12 red led
Operating
temperature
0-45°C, humidity 35..95uR%
Sealing IP54 on front panel
Material Shock-resistant polystyrene
Weight Approx. 400 g
