Pixsys PL260 User Manual

39
SM101
1101
Serial baudrate COM1
(default 9600 baud)
SM111
1111
Serial/canbus baudrate EXP1
(default 9600 baud)
SM121
1121
Serial baudrate COM2
(default 19200 baud)
Value selected into this word defines the serial port
communication speed
5
.
R/W
0  110 baud
1  150 baud
2  300 baud
3  600 baud
4  1200 baud
5  2400 baud
6  4800 baud
7  9600 baud
8  19200 baud
9  28800 baud
10  38400 baud
11  57600 baud
Value selected into this word defines port EXP1
communication speed in EXP-I/O-CANBUS mode:
0  110 baud
1  150 baud
2  300 baud
3  600 baud
4  4800 baud
5  9600 baud
6  19200 baud
7  28800 baud
SM102
1102
Serial COM1 format
SM112
1112
Serial EXP1 format
SM122
1122
Serial COM2
6
forma
t
Value selected into this word defines the serial port
communication data
7
.
R/W
0  8,N,1 (default)
1  8,O,1
2  8,E,1
3  7,N,1
4  7,O,1
5  7,E,1
6  8,N,2
7  8,O,2
8  8,E,2
9  7,N,2
10  7,O,2
11  7,E,2
5
To enable modifications it is necessary to set this word within initialization
function. If no modification has been completed or if it has been done in
other sections of the program, baud-rate will be kept as default at starting.
6
Format may not be modified (8,N,1).
7
To enable modifications it is necessary to set this word within initialization
function. If no modification has been completed or if it has been done in
other sections of the program, baud-rate will be kept as default at starting.
