PLANET ECLIPSE MG 100 - Loading; Reloading

Loading Paintballs
FIG-1
Cover both magazine chambers with your hand then pull one magazine
chamber cover
A
down to open.
FIG-2
Insert paintballs
B
one by one into the magazine chamber.
FIG-3
Once 5 or 10 rounds are loaded (capacity dependant) press gently
downwards to engage the follower retainer. Next press the chamber
cover release button
C
to close
A
. Repeat for the next chamber.
Loading shaped rounds
FIG-4
Repeat the process as explained in Fig-1.
FIG-5
Insert shaped rounds
D
one by one into the magazine chamber, with the
front of the round facing towards the centre of the magazine.
FIG-6
Repeat the process as explained in Fig-3.
FIG-1
FIG-4
FIG-2
FIG-5
FIG-3
FIG-6
B
D
A
A
A
A
C
C
!
!
DO NOT depress the magazine follower without paintballs in the magazine.
On rare occasions releasing a locked follower without paintballs in place can
seriously damage the magazine. NEVER discharge a fully locked follower at
yourself or anyone else.
16
MG 100
QUICK START
LOADING / RELOADING
!
!
WARNING!
Loaded magazines will eject paintballs as soon as the chamber cover opens.
DO NOT open the chamber cover while the magazine is pointed at your (or
anyone’s) face. For safety always place your hand over the top of a magazine
before opening the chamber covers.
WARNING
