FIG-1
37
MG 100
TECHNICAL
THREE-WAY ASSEMBLY
#6 Seal (custom)
#6 Seal (custom)
4 x 1 NBR70
Three-way valve capThree-way valve cap
Three-way valve spool
Three-way valve body
Three-way valve gasket
MG 100 transfer block
Three-way valve gasket
