PLANET ECLIPSE MG 100 - Velocity Adjustment

FIG-1
1
- +
1/8
A
B
24
MG 100
QUICK START
VELOCITY ADJUSTMENT
FIG-1
Insert a 1/8 hex key
A
into the velocity adjuster screw
B
to alter the
velocity of the MG 100.
Adjusting the velocity:
1
Turn the hex key clockwise to reduce velocity.
2
Turn the hex key counter-clockwise to increase velocity.
3
Fire two clearing shots after each velocity adjustment for an
accurate velocity reading.
1
DO NOT turn the adjuster screw in too far. This will prevent the
MG 100 from ring.
2
DO NOT exceed 300 FPS when using .68 calibre paintballs.
3
DO NOT exceed 300 FPS when using shaped rounds.
WARNING!
ALWAYS conform with the velocity limits of the venue and/or local laws.
ALWAYS wear correct protective equipment when ring your marker.
NEVER point your marker in the direction of other people when not on the eld.
ALWAYS be aware of where the barrel is facing when adjusting the velocity.
WARNING
