Planet GT-906B60 - Page 10

Dimensions 94 x 70 x 26mm (W x D x H)
Operator Environment
Operating temperature: 0 to 50 Degree C; Humidity: 5~90% non-condensing
Storage Environment
storage temperature: -10 to 70 Degree C; Humidity: 5~90% non-condensing
Emissions FCC Class A, CE Class A
Model GT-906A60 GT-906B60 GT-906A80 GT-906B80
Hardware Specification
Standards
IEEE 802.3, 10Base-T
IEEE 802.3u, 100Base-TX
IEEE 802.3ab, 1000Base-T
IEEE 802.3z, 1000Base-LX
Ports
1 x 10/100/1000Base-T port,
1 x 1000Base-LX WDM port
Copper Interface RJ-45 port (Auto-MDI/MDI-X) Twisted Pair
Optic Interface WDM
Optic Wavelength
TX:1310nm
RX:1550nm
TX:1550nm
RX:1310nm
TX:1510nm
RX:1570nm
TX:1570nm
RX:1510nm
Max.
+4 dBm
+5 dBm +3 dBm +3 dBm
Launch
Power (dBm)
Min.
-1 dBm
0 dBm -2 dBm -2 dBm
Receive Sensitivity -21 dBm -25 dBm -26 dBm -26 dBm
Maximum Input power -2 dBm -2 dBm -1 dBm -1 dBm
Twisted-pair
10/20Mbps for Half / Full-Duplex
100/200Mbps for Half / Full-Duplex
2000Mbps for Full-Duplex
Speed
Fiber-optic 2000Mbps for Full-Duplex
Twisted-pair
10Base-T: 2-pair UTP Cat. 3,4,5, up to 100 m
100Base-TX: 2-pair UTP Cat. 5, up to 100 m
1000Base-T: 4-pair STP Cat 5 up to 100m
Cable
Fiber-optic
Cable
 50/125μm or 62.5/125μm multi-mode fiber cable, up to 550m.
 9/125μm single-mode cable, provides long distance for 60/80km
LED Indicator y PWR,
y TP LINK/ACT, 1000
y Fiber LINK/ACT
Power Consumption 3.8 Watts/ 13 BTU (maximum)
Power Input DC 5V / 2A
Dimensions 94 x 70 x 26mm (W x D x H)
Operator Environment
Operating temperature: 0 to 50 Degree C; Humidity: 5~90% non-condensing
Storage Environment
storage temperature: -10 to 70 Degree C; Humidity: 5~90% non-condensing
Emissions FCC Class A, CE Class A
-5-
