Planet GT-906B60 - Product Features

1.4 Product Features
 Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z
1000Base-SX/LX
 One-channel media conversion between 10/100/1000Base-T and 1000Base-SX / LX
 TP port supports 10/100/1000Base-T auto-negotiation and auto-MDI/MDI-X
 1000Base-SX: 50/125μm or 62.5/125μm multi-mode fiber cable, up to 220/550m on GT-902
 1000Base-LX: 9/125μm single-mode cable provides long distance for 10km on GT-902S
 1000Base-LX WDM interface for up to 15km (single-mode fiber 9μm/125μm) on GT-906A15/B15
 1000Base-LX WDM interface for up to 60km (single-mode fiber 9μm/125μm) on GT-906A60/B60
 1000Base-LX WDM interface for up to 80km (single-mode fiber 9μm/125μm) on GT-906A80/B80
 1000Base-T: 2-pair Cat. 5/5e/6 UTP cable, up to 100 meters
 Compacts size for working with PLANET MC family Media Chassis ( MC-700/1500/1500R / 1500R48)
 Wall-mountable hardware designed
 Built-in IP-Base Web interface for remote management
 Layer 2 Management Feature
; Store-and-Forward mechanism
; Built-in Web operation interface for remote management and setup
; Manual IP address setting / DHCP client for IP address assignment
; SNMP v1 / v2c monitor / private Enterprise MIB
; Event trap and SNMP trap support
; Speed duplex mode configuration / Flow Control setting / bandwidth Control on TP / Fiber port
; Supports Port Status / Ethernet Statistics on both TP and Fiber interface
; Supports Maximum frame size to 16K bytes
; Loop detection / Broadcast / Multicast / Unicast storm control
; Management VLAN / 16 IEEE 802.1Q VLAN groups / Q-in-Q VLAN
-3-
