Flow Control
Allow Disable or Enable Flow Control of TP or Fiber port.
• Enable – IEEE 802.3x Flow Control is enabled on Full-Duplex mode or
Backpressure is enabled on Half-Duplex mode
• Disable – No Flow Control or backpressure function on no matter
Full-Duplex or Half-Duplex mode
Default mode: Disable
Ingress Rate Limit
The value of inbound traffic limitation in kilobit-per-second (kbps). The available
options are :
• No Limit
• 512K
• 1M
• 2M
• 4M
• 8M
• 10M
• 50M
• 100M
• 500M
Default mode: No Limit
The Ingress Rate Limit configuration field as show in Figure 4-21.
Egress Shaping
The value of outbound traffic limitation in kilobit-per-second (kbps). The available
options are :
• No Limit
• 512K
• 1M
• 2M
• 4M
• 8M
• 10M
• 50M
• 100M
• 500M
Default mode: No Limit
The Egress Shaping configuration field as show in Figure 4-22.
Apply button
Press this button for save current configuration of Managed Media Converter.
Refresh button
Press “Refresh” button to refresh current status.
Table 4-6 Descriptions of the Port Configuration Web Page Screen Objects
-30-
