The Quality of Service Web page includes the following configurable data:
Qos Mode
Provide 4 different QoS mode for operation, the available options are:
Disable
802.1p Tag Priority
The 802.1p Tag Priority field as show in Figure 4-32.
IP Address Priority
The IP Address Priority field as show in Figure 4-33.
IP DSCP Priority
The IP DSCP Priority field as show in Figure 4-34.
Default mode is Disable.
Scheduling
Provide two scheduling method for Quality of Service, the available options are:
Strict Priority
Weighted Round Robin (16:8:4:1)
Default mode is Strict Priority.
Apply button
Press this button for save current configuration of Managed Media Converter.
Table 4-12 Descriptions of the Quality of Service Web Page Screen Objects
Figure 4-32 802.1p Tag Priority Web Page screen
-42-
