User’s Manual of PL-510W
10
Security
128-bit AES link encryption with key management
Data PHY Rate
200Mbps over Powerline and 10/100Mbps over Ethernet
Modulation Schemes
OFDM symbol modulation on line synchronization
1024/256/64/16/8 - QAM, QPSK, BPSK, ROBO carrier
modulation
Frequency Band
2 ~ 30 MHz
Additional Protocols
Mix of TDMA and CSMA/CA channel access scheme;
CO device generates a periodic beacon carrier for channel
access scheme
QoS prioritizes both wired and wireless Internet traffic to
bandwidthsensitive applications like online gaming, IPTV or
stream multimedia
Operation Range
Estimated range of 300 meters in wall powerline
Environment Specifications
Operating
Temperature: 0~40 Degree C
Relative Humidity:10~90% (non-condensing)
Storage
Temperature: -40~70 Degree C
Relative Humidity: 0~90% (non-condensing)
Power Supply
100~240V AC, 50~60Hz internal
Housing Dimension
(W x D x H)
94 x 29.85 x 32 mm
Weight
94 g
Emission
FCC, CE
