1.4 Product Specification
Model PL-510W
Hardware Specification
Network Interface
One RJ-45 port (10/100Base-T Ethernet)
One 200Mbps power line port supporting co-existence with
HomePlug 1.0
Antenna
Gain: 2 x Internal 2.5dBi Antenna
Orientation: Horizontal and Vertical
Cabling
Cat. 5 UTP cable
LED
Power：On / Off
Ethernet： Solid / Blinking / Off
Data：Solid / Blinking / Off
WLAN：Solid / Blinking / Off
WPS：Solid / Blinking / Off
Buttons
One WPS / Reset button
One Pair button
Wireless Interface Specification
Standard
IEEE 802.11b/g/n
Working mode
AP mode
Frequency Band
2.4~2.4835GHz
Data Transmission Rates
802.11b: 11/5.5/2/1Mbps (Dynamic)
802.11g: 54/48/36/24/18/12/9/6Mbps (Dynamic)
802.11n (40MHz): 270/243/216/162/108/81/54/27Mbps
135/121.5/108/81/54/40.5/27/13.5Mbps (Dynamic)
802.11n (20MHz): 130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps (Dynamic)
Transmission Distance
Indoor up to 100m
Channel
America / FCC: 2.412~2.462GHz (11 Channels)
Europe / ETSI: 2.412~2.472GHz (13 Channels)
Japan / TELEC: 2.412~2.484GHz (14 Channels)
Channel Width
20 / 40MHz
Max. RF Power
802.11b: 17±1.5dBm
802.11g: 14.5±1.5dBm
802.11n (20MHz): 12.5±1.5dBm
802.11n (40MHz): 12.5±1.5dBm
Receive Sensitivity
802.11b: -92dBm @ 1Mbps; -85dBm @ 11Mbps, PER < 8%
802.11g: -88dBm @ 6Mbps; -73dBm @ 54Mbps, PER <10%
802.11n: -90dBm @ MCS8; -70dBm @ MCS15, PER <10%
Encryption Security
WEP (64/128-bit) encryption security
WPA / WPA2 (TKIP/AES)
WPA-PSK / WPA2-PSK (TKIP/AES)
Standards Conformance
Computer Interface
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
Standards
IEEE 1901 / HomePlug AV
