21
Refer to the following procedure to set up the VDSL2 Bridge to
IP DSLAM connection.
1. [Remote End] Set the remote IP DSLAM/VDSL2 switch to
CO mode with proper VDSL2 prole.
2. [Local End] Set the VDSL2 Bridge at the local end to CPE
mode from the DIP switch.
3. Power on the VDSL2 Bridge CPEs by connecting its power
source.
4. Power LED will illuminate.
5. Connect VDSL line from IP DSLAM/VDSL2 switch to RJ11
VDSL port of the VDSL2 Bridge.
6. VDSL LNK LED will blink to illuminate.
7. Connect telephone to the RJ11 Phone port of the VDSL2
Bridge.
8. Connect the VDSL2 Bridge Ethernet LAN port to other
network device via regular Cat.5 UTP cable.
When deciding where to put the converter and / or prolong the
operational life of the bridge, please also refer to the following
points:
It is accessible and cables can be connected easily.
Cabling is away from sources of electrical noise such as
radios, transmitters, motors, power lines and uorescent
lighting xtures.
Do not place objects on top of any unit or stack.
Water or moisture cannot enter the VDSL2 Bridge.
Air owing around the unit and through the vents on the side
of the case is not restricted (We recommend that you provide
a minimum of 25mm clearance.).
