Planet VC-231G - Point-to-Multipoint Application Guide

19
4. Power LED will illuminate.
5. Connect VDSL line from another VDSL device to RJ11 VDSL
port of the VDSL2 Bridge.
6. VDSL LNK LED will blink to illuminate at both VDSL2
bridges.
7. Connect telephone to the RJ11 Phone port of the VDSL2
Bridge.
8. Connect the VDSL2 Bridge Ethernet LAN port to other
network device via regular Cat.5 UTP cable for VC-231G/
VC-234G or optical ber cable for VC-231GF.
4.2 Point-to-Multipoint Application -- Connect to IP
DSLAM
To build a local Internet in apartments, hotels and campuses
and hospitality environments, it requires:
 The multi-port VDSL2 IP DSLAM or VDSL2 switch (for
example, PLANET VC-820M) operates as a CO Master and
needs to be placed in the wiring center (MDF room) and
connects to the telephone line system.
 On the other hand, it needs to install one or many CPE
Slaves (the VC-231G or VC-234G VDSL Bridge) on the
individual client side and connect to the multi-port Master
through the telephone lines.
