5.ProductSpecications
Product VC-231G VC-231GF VC-234G
Hardware Specications
LAN Ports
1 10/100/1000
BASE-T RJ45
auto-MDI/MDI-X
port
1 1000BASE-SX/
LX/BX SFP slot
4 10/100/1000
BASE-T RJ45
auto-MDI/MDI-X
ports
VDSL Port
1 VDSL2 RJ11 female phone jack
Twisted-pair telephone wires (AWG24 or better) up to
1.4km
Phone Port
Additional splitter for POTS
connection
1 RJ11, built-in
splitters for POTS
connection
Dimensions
(W x D x H)
97 x 70 x 26 mm
154.6 x 86.0 x
26.3 mm
Weight 184g 180g 350g
Power
Requirement
DC 5V, 2A external power
LED
Indicators
 Power: Green
 1000BASE-T LNK/ACT: Green
 100BASE-TX LNK/ACK: Green
 VDSL: Green
 CO: Green
 CPE: Green
Housing Metal
DIP
Switch &
Functionality
4-position DIP switch
 CO/CPE mode select
 Selectable G.INP and interleaved mode
 Selectable target Band Prole
 Selectable target SNR mode

Planet VC-231G Specifications

General

Maximum data transfer rate	1000 Mbit/s
Auto MDI/MDI-X	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Material	Metal
Product type	Network bridge
Product color	Black
Power requirements	DC 5V, 2A
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	184 g
Dimensions (WxDxH)	97 x 70 x 26 mm
