Planet VIP-1010PT - Advanced Features: Music, Encryption, and NAT

High Definition PoE IP Phone (1-Line)
VIP-1010PT
- 46 -
Music Server
Address
To display or configure third-party MOH (music-on-hold)
server.
Active: To enable or disable this MOH server. If enabled,
the IP phone will play MOH from configured server.
Music Server Address: To configure MOH server address.
Session Timer To display or configure session timer settings.
Active: To enable or disable this feature. If enabled, the
ongoing call will be disconnected automatically once the
session expired unless it’s been refreshed by UAC or UAS.
Session Expire: Configure session expiry time.
Session Refresher: To configure who should respond for
refreshing a session.
UAC means User Agent Client and here stands
for IP phone. UAS means User Agent Server
and here stands for SIP server.
Broadsoft To display or configure Broadsoft AOC feature.
AOC: A feature is used to be accounted on Broadsoft
platform.
Please consult your administrator or Planet Technical
support for further information.
Encryption To enable or disable SRTP feature.
Voice Encryption (SRTP): If enabled, all audio signals
(technically speaking it’s RTP streams) will be encrypted
for more security.
NAT To display NAT-related settings.
UDP keepalive message: If enabled, IP phone will send
UDP keepalive message periodically to router to keep NAT
port alive.
UDP Alive Msg Interval: Keepalive message interval.
Rport: Remote Port; if enabled, it will add Remote Port
into outgoing SIP message for designated account.
