High Definition PoE IP Phone (1-Line)
VIP-1010PT
- 72 -
User name: Configure if server needs a username to
access, otherwise left blank.
Password: Configure if server needs a password to
access, otherwise left blank.
Common AES Key: Used for IP phone to decipher
common Auto Provisioning configuration file (For the
VIP-1010PT, this configuration file is
r000000000053.conf.).
AES Key(MAC):Used for IP phone to decipher
MAC-oriented auto portioning configuration file(for
example, file name could be 00304f888888.conf if IP
phone’s MAC address is 00304f888888.).
Note: AES is one of many encryptions. It should be
configured only if the configure file is ciphered with AES,
otherwise left blank.
AutoP To display and configure Auto Provisioning mode
settings.
This Auto Provisioning mode is actually
self-explanatory.
For example, mode “Power on” means IP phone will go
to do Provisioning every time it powers on.
System Log To display syslog level and export syslog file.
Syslog level: From level 0~7. The higher level means
the more specific syslog is saved to a temporary file.
By default, it’s level 3.
Export Log: Click to export temporary syslog file to local
PC.
PCAP To start, stop packets capturing or to export captured
Packet file.
Start: To start capturing all the packets file sent or
received from IP phone.
Stop: To stop capturing packets.
Note: IP phone will save captured packets file to a
temporary file; this file maximum size is 1M
(megabytes), and will stop capturing once this
maximum size is reached.
Others To display or configure other features from this page.
Configure file: To export or import configure file for IP
phone.
