▫ High back-plane bandwidth 5Gbps
▫ Console/Web/SNMP management
▫ Configuration backup and recovery
▫ Per port Ingress/Egress bandwidth restriction
▫ Configurable spanning tree aging time, STP port configuration
▫ 12 trunk groups, up to 8 ports per trunk
▫ Port-based/802.1Q VLAN with 4K VLAN ID
▫ MAC Binding/Filtering/Learning, configurable MAC Aging time
▫ 8 mappings ID to 4 priority queues, Support MAC/VLAN/802.1p/Port to CoS mapping
▫ IGMP snooping and IGMP Query mode for Multi-media application
▫ Statistic Routing Port
▫ 1 to many Ingress/Egress Port mirror and Port analysis
▫ Broadcast/Multicast/Flooded storm control
1.4 Product Specification
Hardware Specification
Network Connector 24-Port RJ-45 for 10/100Base-TX
1 open slot for 100Base-FX fiber-optic interface
RS-232 connector One RS-232 DB-9 male connector for switch management
Switch architecture Store and forward switch architecture.
Switch Fabric Back-plan up to 5Gbps
MAC address 8K MAC address table with Auto learning function
Shared Buffer 3Mbit
Power requirement 90~240V AC, 50/60Hz,
Operating environment 0 ~50 degree C, 5%~90%RH
Storage environment -20~70 degree C, 5%~90%RH
Dimension (W x D x H) 440 x 200 x 44 mm
Switch Specification
Spanning Tree 802.1d, 802.1w
Link Aggregation 12 groups, up to 8 ports per group
Priority Queue 802.1p Class of Service (4 Queues)
Port Mirror RX/TX/Both
Bandwidth Control Yes, per port per 64kbps, up to 80Mbps
Strom Control Per 64kbps, up to 80Mbps
IGMP Snooping V1
MAC Filtering Yes
LAN Port-Based/802.1q, 4K VLAN ID, 256 groups
Port Analysis Yes
Static Routing Port Yes
Management Function
Management Interface Console/Web/Telnet/SNMP
SNMP Version V2
Support MIB Support SNMP MIBⅡ(RFC 1213),
