Planmeca Proline EC Panoramic X-ray 47
TECHNICAL SPECIFICATIONS
User's manual
Mechanical data
Weight Panoramic:108 kg / 238 lbs
Pan/ceph 126 kg / 278 lbs
Dimensions (HxDxW) 2200x930x890 mm, 86.6x36.6x35 inch
Color RAL 9002
Environmental requirements
Ambient temperature Operating +5°C to +40°C
Storage -10°C to +50°C (film-based X-ray)
0°C to +50°C (Dimax3 digital X-ray system)
Humidity 25% - 75%
Manufacturer
PLANMECA Oy, Asentajankatu 6, 00880 Helsinki, FINLAND
phone: +358 20 7795 500
NOTE For information given in User’s statement
please refer to Planmeca Proline EC X-ray
unit’s technical manual.
OPTIMUM SPACE REQUIREMENTS:
X-RAY W H D
Planmeca Proline EC panoramic X-
ray
1535mm
60 in
2250 mm
89 in
1250 mm
49 in
Planmeca Proline EC panoramic X-
ray with Autoprint
1630 mm
64 in
2250 mm
89 in
1250 mm
49 in
Planmeca Proline EC Panoramic X-
ray and Cephalostat CM
2250mm
60 in
2250 mm
89 in
1250 mm
49 in
