Prostyle Intra X-ray Unit 5
MAIN PARTS
User's manual
Horizontal tube head stiffness adjustment screw
Adjust the stiffness of the tube head horizontal move-
ment by turning the adjustment screw on the support
axle manually or with a wrench tool.
The stiffness of the tube head horizontal movement
has been preadjusted at the factory, and can be chan-
ged by the user, if necessary.
Turn the adjustment screw 0,5 - 1 rounds clockwise if
you want to tighten the tube head and 0,5 - 1 rounds
counterclockwise to loosen it.
NOTE Do not turn the adjustment screw too much counter-
clockwise to avoid the screw to come loose.
intra_stiffness.eps
Horizontal tube head stiffness adjustment screw
