MAIN PARTS
4 Prostyle Intra X-ray Unit
User's manual
4 MAIN PARTS
One end of the control panel cable is connected to the
terminal at the under-side of the generator box, and the
other end to the control panel.
CAUTION Do not connect any other equipment to the control
panel’s terminal.
Prostyle
Support arm
Generator box
Control panel
Tube head
Scale for cone angle
