Section 2. Installing the PX-760A Internal ATAPI Drive
24 PX-760 Installation and Users Manual
Select an IDE Configuration
Set the PX-760A’s jumper and cable it according to the desired
configuration. Keep these rules in mind:
• For best DVD±RW and CD-RW performance, try to connect the
PX-760A to the IDE port that is not connected to the hard disk drive
or to a DVD or CD-ROM drive. In most cases, this will be the
secondary IDE port.
• For best results, set the PX-760A to be the Master, if possible.
• If you have only one device on a cable, always set its jumper as the
Master, never as the Slave.
Before PX-760A
Installation
How to Install the
PX-760A
A
Hard disks connected as
Master and Slave devices on
primary IDE port; DVD-ROM or
CD-ROM drive connected as
Master device on secondary
IDE port.
Remove the DVD-ROM or
CD-ROM drive, change it to
Slave, and re-connect it to the
secondary IDE port.
Set the mode jumper to Master,
and connect the PX-760A as
Master device to the secondary
IDE port.
Figure 8. How to install the PX-760A if your computer is originally
set up in configuration A
