Appendix A: PX-760 Specifications
PX-760 Installation and Users Manual 85
Rear Panel, PX-760A Internal ATAPI Drive
Power Supply DC +12V,
±10%
DC +5V,
±5%
Typical standby current 100 mA 230 mA
Typical DVD read
current (DVD 16X)
1.4 A 700 mA
Typical CD read current
(CD 48X)
1.4 A 750 mA
Typical DVD write
current (DVD+R 18X)
1.4 A 1.4 A
Typical write current
(CD-R 48X)
1.4 A 800 mA
Typical pause current 1.0 A 700 mA
Peak current 2.3 A 1.7 A
Power
Consumption
Average 22.2 W for DVD read/write
IDE Interface
Connector
IDE bus, 40-pin flat ribbon type. Interface complies
with ATA/ATAPI-5. Must use 80-conductor IDE/ATA
cable.
NOTE: Although the PX-760A will operate with a 40-
conductor cable, it may not be able to write at 18X
unless an 80-conductor IDE/ATA cable is used.
Maximum total cable length cannot exceed 18 in
(45.7 cm).
Analog Audio
Output
Connector
Not used
Digital Audio
Output
Connector
Digital audio output for input to SPDIF or Digital-In
input
Mode Jumper Master (default), slave, cable select (CSEL)
