Plextor StorX - Buttons and Indicators

Buttons and Indicators
Power Button
Power
LAN
HDD LINK
HDD ACCESS
USB II LINK
USB II ACCESS
USB I LINK
USB I ACCESS
Backup Button
LED Indicators
6 of 46
Power LED Green – System ready
LAN LED Green – Valid Connection at 10/100/1000 Mbps
HDD LINK Green – HDD ready
HDD ACCESS Yellow – Data transmitting on HDD
USB I / II LINK Green – Valid connection on USB I / USB II port
USB I / II ACCESS Yellow – USB I / II PORT Active
