PMC PH-2 - Page 85

PH/PHX-2 Manual
85
PH-2 (LOW PRESSURE)
PHX-2 (HIGH PRESSURE)
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
FR-10
FRAME ASSY, PH(X)-2 (SEE PAGE 53)
2
1
PH-21
HEATER ASSY; PH(X)-2 (SEE PAGE 75)
1
PH-22
HEATER ASSY; PH(X)-2 (SEE PAGE 75)
1
PH-23
HEATER ASSY; PH(X)-2 (SEE PAGE 75)
3
1
HI-05331
EXIT MANIFOLD ASSY (SEE PAGE 56)
4
1
PL-9
PUMPLINE, PH-2 (SEE PAGE 69)
1
PL-10
PUMPLINE, PHX-2 (SEE PAGE 71)
5
52
FLOOR STOCK
1/4" WASHER
6
4
FLOOR STOCK
1/4-20 X 1 HEX BOLT
7
1
HI-05335
HYDRAULIC MANIFOLD ASSY (SEE PAGE 55)
8
4
FLOOR STOCK
1/4-20 HEX NUT
9
2
HI-05304
HYD CYLINDER TUBE
10
4
FLOOR STOCK
5/16" WASHER
11
34
FLOOR STOCK
1/4" LOCK WASHER
12
4
FLOOR STOCK
5/16" LOCK WASHER
13
2
PU-07006
PROXIMITY MOUNT
14
4
FLOOR STOCK
M10 X 1.5 JAM NUT
15
2
PU-07000
CLEAR PUMP COVER
16
1
HI-05328
LUBE CYLINDER EXT
17
1
YS-6
A INLET MANIFOLD ASSY (SEE PAGE 73)
18
1
YS-7
R INLET MONIFOLD ASSY (SEE PAGE 74)
19
1
EL-35-1
HEAT SINK
20
1
EL-35
HOSE HEAT RELAY
21
1
EL-00118A-00-1
HOSE BREAKER MOUNTING PLATE
22
1
EL-192
TERMINAL BLOCK
23
1
EL-193
INRUSH CURRENT LIMITER
24
1
EL-150
CIRCUIT BRAKER, 63AMP
25
1
EL-05228
70V TRANSFORMER
1
EL-05225
90V TRANSFORMER
1
EL-05226
120V TRANSFORMER
26
2
EL-000P12
HEYCO #6
27
19
FLOOR STOCK
#8-32 X 1/4 HEX SOCKET BUTTON HEAD CAP SCREW
28
2
EL-153
12MM PROX SWITCH
29
1
MQ-01009-01A
LUBE BOTTLE
30
1
MQ-01009-02A
LUBE BOTTLE LID
31
1
HI-05327
3/8 OD X 1/4 NPT 90 DEG
32
1
HI-05003
DIRECTIONAL VALVE
33
24
FLOOR STOCK
1/4-20 X 3/4 HEX CAP SCREW
