PMC PH-2 - Page 86

PH/PHX-2 Manual
86
34
2
EL-05220-01
CONSOLE KNOBS
35
2
FLOOR STOCK
#8-32 X 1-3/4 CROSS RECESSED PAN HEAD MACHINE SCREW
36
6
HI-001
PLASTIC TUBE CAPS
36
1
FLOOR STOCK
#8-32 X 1 CROSS RECESSED PAN HEAD MACHINE SCREW
37
3
FLOOR STOCK
#8-32 HEX NUT
38
4
FLOOR STOCK
#10-32 X 5/16 CROSS RECESSED PAN HEAD MACHINE SCREW
39
1
CL-03000
HEATER COVER
40
2
CL-03001
HEATER COVER END CAPS
41
8
FLOOR STOCK
1/4-20 X 3/4 HEX SOCKET BUTTON HEAD CAP SCREW
42
1
EL-000P7
HAYCO SR
43
4
FLOOR STOCK
#10-24 X 2 HEX SHCS
44
4
EL-00052
SOLENOID VALVE CONNECTOR
45
4
EL-00053
SOLENOID VALVE GASKET
46
4
EL-158
MICRO CORDSET 90 DEGREE
47
2
HI-05339
12 JIC X 16 JIC SW 90 DEG (PH-2)
2
HI-05342
12 JIC X 12 NPTM 90 DEG (PHX-2)
48
1
HI-05321
1/4 NPT X 1/2 TUBE 90 DEG
49
1
EL-400-31
CONSOLE ASSY, 3HP, 1PH
1
EL-400-33
CONSOLE ASSY, 3HP, 3PH
50
2
EL-42-2200
PRESSURE SWITCH; 2200 PSI
2
EL-42-3200
PRESSURE SWITCH; 3200 PSI
51
2
HI-05345
6 JIC X 1/4 NPT "T"
52
2
HI-05346
1/4 NPTF 90 DEG
53
2
HI-05347
3/8 NPT X 6 JIC 90 DEG
54
1
ML-1
MOTOR LINE ASSEMBLY; 3HP; 3PH; 60HZ (SEE PAGE 80)
1
ML-2
MOTOR LINE ASSEMBLY; 3HP; 1PH; 60HZ (SEE PAGE 78)
1
ML-3
MOTOR LINE ASSEMBLY; 5HP; 1PH; 60HZ (SEE PAGE 78)
1
ML-4
MOTOR LINE ASSEMBLY; 5HP; 3PH; 60HZ (SEE PAGE 80)
55
6
FLOOR STOCK
3/8" LOCK WASHER
56
1
EL-05230-03
RT ANGLE CONDUIT CONNNECTOR
57
6
FLOOR STOCK
3/8" WASHER
58
20
FLOOR STOCK
1/4-20 X 1 HEX CAP SCREW
59
4
FLOOR STOCK
5/16-18 X 7/8 HEX CAP SCREW
60
6
FLOOR STOCK
3/8-16 X 1 HEX CAP SCREW
