SVM-10 Manual
Implementation of new developments and product improvements may result in specification changes in this
document
Environmental
Operating temperature -20°F to 135°F
Shock 60Hz to 2KHz,
acceleration 25G
Vibration 10Hz to 60Hz,
amplitude 1.8mm
Physical Dimensions
Size 6.5” x 6.5” x 4.25”
Weight 5.0 lbs.
Case NEMA 4X
Power Fail Operation
The device operates with no input voltage for more
than 30 minutes. This allows it to measure down to 0
volts on all channels during power outage periods.
Harmonics (optional)
Voltage
Measures:
Magnitude
Phase
THD
Waveform capture:
Measures to the 51
st
Triggered
Type
Size
Interface
Wide-temperature LCD
4 lines by 20 characters
Menu-driven
SVM-10™ Specifications Continued..
Controls
Stripchart settings 1 second to 4 hours
Significant change 1V to 8 V, in 1V steps
Battery voltage check Automatic
Keypad 4-key membrane
Power Requirements
Recording load < 1.5 Watts
