SVM-10 Manual
SVM-10™ Series
(*R-models only)
SVM-10™ Manual PMI#XXXXXXX
Serial Adapter PMI#30550106
Wall Transformer PMI#31100008
*Modem Cable PMI#20506001
SVM-10™ Comm. Cable PMI#20506002
Figure 1-6: Cases
1.5 SPECIFICATIONS
1.5.1 General
The SVM-10™ Scanner specifications is shown in Table 1-1.
Table 1-1 SVM-10™ Specifications
SVM-10™ Scanner Specifications
Input
AC Voltage 0 to 10 VAC
Sample rate: samples per second
61,440 all channels
15,360 per channel (256/cycle)
Channels
4 voltage
Measured Qualities
RMS Voltage (Volts)
Note: All quantities are measured for each cycle.
Accuracy/Resolution
(-20°F to 135°F)
Accuracy Percent of full scale
Voltage 0.33 %
Resolution: Displayed/Internal
Voltage 0.01 V / 0.001 V internal
Input Impedance
Channels 1,2,3 12kOhms
Channel 4 500 Ohms
Information Storage
Memory
RAM 128K (battery-backed)
FLASH EPROM 512K to 2,048K
DSP Waveform RAM up to 256K
TOTAL MEMORY 1.1 million readings
Capacity
Summary data Over 1 year
Event data 500 records
Significant change data 500 records
Stripcharts 4 hours to over 1 yr.
Voltage
Retention time > 5 years
Communications
Local
Type Serial Cable
Standards RS232 Compatible
Data rate 1,200 to 38,400 baud
Modem (optional): 14.4 kbps
Local Output
