poclain hydraulics MK08 - Page 81

POCLAIN HYDRAULICS
800078181E DOC-REPAIR-MK05-MKE18-FR-EN 81
• Mandrin pour remonter la
coiffe de frein.
• Mandrel for
reassembling the brake cover.
ØB / B dia
ØA / A dia
F
G
ØD
D dia
C
E
MX
Moletage
Milling
Ø A Ø B C Ø D E F G
mm
[inch]
mm
[inch]
mm
[inch]
mm
[inch]
mm
[inch]
mm
[inch]
mm
[inch]
F05 M12 125
[4.92]
115
[4.52]
F08 125
[4.92]
115
[4.52]
151
[5.94]
159
[6.25]
50
[1.96]
10
[0.39]
20
[0.78]
F11
F18
F21
M16
190
[7.48]
180
[7.08]
180
[7.08]
205
[8.07]
215
[8.46]
50
[1.96]
10
[0.39]
• Mandrin pour remonter
la bague d’étanchéité (027)
ou (078)
• Mandrel for
reassembling the sealing
ring (027) or (078)
ØB / B dia
ØA / A dia
F
G
ØD
D dia
C
E
MX
Moleta
g
e
Milling
Ø A Ø B C Ø D E F G
mm
[in]
mm
[in]
mm
[in]
mm
[in]
mm
[in]
mm
[in]
mm
[in]
MK05
162
[6.37]
175
[6.88]
100
[3.93]
35
[1.37]
10
[.39]
10
[.39]
25
[.98]
MK08
192
[7.55]
198
[7.79]
100
[3.93]
35
[1.37]
10
[.39]
10
[.39]
25
[.98]
MK09
193
[7.56]
202
[7.95]
100
[3.93]
35
[1.37]
10
[.39]
10
[.39]
25
[.98]
MK11
238
[9.37]
248
[9.76]
100
[3.93]
35
[1.37]
10
[.39]
10
[.39]
25
[.98]
MK18
MKE18
238
[9.37]
248
[9.76]
100
[3.93]
35
[1.37]
10
[.39]
10
[.39]
25
[.98]
