ENGINE

2.19

ENGINE ASSEMBLY

5. Make sure oil pump area is clean. Install oil pump

and torque to specification. Install new stator

gasket.

6. Install stator. Torque bolts to specification.

7. Inspect flywheel key for damage. Replace if

necessary. Install flywheel and torque to

specification.

8. Install driven clutch shaft components and shaft

assembly.

Oil Pump Bolt Torque:

43 in.lbs. (5 Nm)

Stator Mounting Bolt Torque:

84 in.lbs. (9.5 Nm)

Flywheel Nut Torque:

25 ft.lbs. (34 Nm)
