ENGINE
2.20
ENGINE ASSEMBLY
9. Install new transmission cover gasket and install
transmission cover. Torque bolts to specification.
10. Add the specified amount of oil to the transmission
gear case. Inspect for leaks.
11. Install the starter clutch, starter gear, needle
bearing, and washer.
12. Install the plate, shaft pin, washers, and idler gear.
13. Install idle gear bolts and torque to specification.
Transmission Cover Bolt Torque:
84 in.lbs. (9.5 Nm)
Gear Case Oil Specification:
10 fl.oz. (300 ml)
Polaris Premium Synthetic
Gearcase Lubricant:
PN 2871477 (Gallon)
PN 2871478 (12 oz.)
Idler Gear Bolt Torque:
84 in.lbs. (9.5 Nm)
