ENGINE
2.21
ENGINE ASSEMBLY
14. Install oil ring, driven clutch, and driven clutch nut on
output shaft. Torque nut to specification
15. Install primary clutch sheave.
16. Install drive belt.
17. Install the primary fixed sheave and claw washer.
Driven Clutch Nut Torque:
25 ft.lbs. (34 Nm)
