3.44
9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
28.Connect the PBR connectors
2#
and Stator connector
2$
to the PBR.
29.Install the spark plugs
2@
. Torque to specification.
TORQUE
Spark Plug:
22 ft-lbs (30 N·m)
30.Connect the ignition coils connectors
2)
to the wire
harness and install the spark plug caps
2!
onto the
spark plugs.
NOTICE
Make sure the spark plug wires snap into place.
Be sure the MAG and PTO plug wires are correct
31.Install the fasteners
l
that retain the support brace
1(
.
TORQUE
Left Support Brace Fasteners:
22 ft-lbs (30 N·m)
32.Install the drive clutch, driven clutch, and drive belt.
See the following procedures for installation:
• Drive Clutch Installation page 7.22
• Driven Clutch Installation page 7.28
• Drive Belt Installation page 2.24
ENGINE / COOLING / EXHAUST
