3
9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
3.45
33.Carefully install the intake plenum assembly
k
into
place.
34.Install the edge clip
j
retaining the wiring harness to
the intake plenum.
35.Connect the ECU to the wiring harness
h
.
36.Carefully install the intake tube assembly
g
.
NOTICE
Ensure the intake tube is properly seated to the air box
and properly aligned with the intake plenum.
37.Install the fastener
f
retaining the lower intake tube.
Torque the fastener to specification.
TORQUE
Lower Intake Tube Fastener:
36 in-lbs (4 N·m)
ENGINE / COOLING / EXHAUST
