1.18
9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
PRO-CC REAR SUSPENSION
ITEM
TORQUE
Spring Roller Shaft
Fastener
17 ft-lbs (23 N·m)
Bogie Wheel Fastener 10 ft-lbs (14 N·m)
Front Cross Shaft
Fastener
33 ft-lbs (45 N·m)
FTS Mounting Fasteners 33 ft-lbs (45 N·m)
Front H-Bracket Fastener
56 ft-lbs (76 N·m)
Rear H-Bracket Fastener
46 ft-lbs (63 N·m)
Rear Cross Shaft
Fastener
33 ft-lbs (45 N·m)
Rear Pivot Arm Fastener
56 ft-lbs (76 N·m)
Idler Fastener
33 ft-lbs (45 N·m)
Limiter Strap Fastener 12 ft-lbs (16 N·m)
Front Torque Arm to
Tunnel Fastener
46 ft-lbs (63 N·m)
Front Torque Arm to Rail
Fastener
56 ft-lbs (76 N·m)
Rear Torque Arm to Rear
Pivot Arm Fastener
33 ft-lbs (45 N·m)
Rear Torque Arm to
Tunnel Fastener
33 ft-lbs (45 N·m)
Rear Mounting Arm
Fasteners
24 ft-lbs (33 N·m)
RTS Mounting Fasteners 24 ft-lbs (33 N·m)
Shock Rod Fasteners
17 ft-lbs (23 N·m)
Shock Pivot Arm to H-
Bracket Fastener
24 ft-lbs (33 N·m)
IGX 146 REAR SUSPENSION
ITEM
TORQUE
Rail Tip Fastener 4 ft-lbs (6 N·m)
Hi-Fax Fastener
4 ft-lbs (6 N·m)
Jounce Bumper Fastener
Torque until screw
protrudes 5mm out of
nut
Wheel Mount Block
Fastener
9 ft-lbs (12 N·m)
Front Torque Arm Bumper
Fasteners
4 ft-lbs (6 N·m)
IGX 146 REAR SUSPENSION
ITEM
TORQUE
Rail Plate Reinforcement
Fasteners
17 ft-lbs (23 N·m)
Spring Roller Shaft
Fastener
17 ft-lbs (23 N·m)
Bogie Wheel Fastener 10 ft-lbs (14 N·m)
Front Cross Shaft
Fastener
33 ft-lbs (45 N·m)
FTS Mounting Shaft
Fastener
50 ft-lbs (68 N·m)
FTS Mounting Fastener 33 ft-lbs (45 N·m)
Rear Pivot Arm Fastener
33 ft-lbs (45 N·m)
RTA Scissor Stop Guide
Fastener
6 ft-lbs (8 N·m)
Idler Fastener
33 ft-lbs (45 N·m)
Limiter Strap Fastener 12 ft-lbs (16 N·m)
Front Torque Arm to
Tunnel Fastener
50 ft-lbs (68 N·m)
Front Torque Arm to Rail
Fastener
46 ft-lbs (63 N·m)
Shock Pivot Fastener
24 ft-lbs (33 N·m)
Rear Torque Arm to Rear
Pivot Arm Fastener
17 ft-lbs (23 N·m)
Rear Torque Arm to
Tunnel Fastener
46 ft-lbs (63 N·m)
Upper Shock Rod
Fastener
33 ft-lbs (45 N·m)
RTS Mounting Fasteners 33 ft-lbs (45 N·m)
SHOCKS
ITEM
TORQUE
Walker Evans Force Shaft
Loop
18 ft-lbs (24 N·m)
Walker Evans Force
Reservoir Body
10 ft-lbs (14 N·m)
Walker Evans Force
Shock Rod Lock Nut
15 ft-lbs (20 N·m)
Walker Evans Force Seal
Head / Bearing Cap
45 ft-lbs (61 N·m)
Walker Evans Force Body
Cap
45 ft-lbs (61 N·m)
GENERAL INFORMATION
