9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
5.13
25.Remove the cable ties
2^
from the wire support and
wire retainer mounted on the engine.
NOTICE
Do not remove the cable tie securing the support to the
coolant hose.
26.Loosen the two gear clamps
2&
that secure the
throttle body to the reed valve / manifold assembly.
27.Pull the throttle body out of the reed valve / manifold
assembly.
28.Loosen the throttle cable lock nut
2*
and remove the
cable from the throttle body.
29.Remove the throttle body from the vehicle.
FUEL SYSTEM
