9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
1.15
BRAKE SYSTEM
ITEM
TORQUE
Master Cylinder to Frame 23 ft-lbs (31 Nm)
Brake Caliper Bleed
Fasteners
44 in-lbs (5 Nm)
BODY / FRAME
ITEM
TORQUE
Body Fasteners 8 ft-lbs (11 Nm)
Upper Instrument Panel
Fasteners
24 in-lbs (2.7 Nm)
Rear Bumper Fasteners 14 ft-lbs (19 Nm)
ROPS Fasteners
30 ft-lbs (41 Nm)
Lower Front ROPS
Fasteners
Built 10/17/2016 or After
42 lb-ft (57 Nm)
Side Bolster Fastener
14 ft-lbs (19 Nm)
Airbox Support 14 ft-lbs (19 Nm)
Rear Bracket
14 ft-lbs (19 Nm)
Rear Chassis Brace
14 ft-lbs (19 Nm)
Door Hinge Screws 8 ft-lbs (11 Nm)
Door Panel Screws
22 In-lbs (2 Nm)
Door Latch Screws
8 ft-lbs (11 Nm)
Latch Bracket Screws
12 ft-lbs (16 Nm)
Skid Plate Fasteners
8 ft-lbs (11 Nm)
Winch Mount Fasteners
8 ft-lbs (11 Nm)
Seat Belt Retractor /
Buckle Fasteners
42 ft-lbs (57 Nm)
Seat to Frame Fasteners
27 in–lbs (3 Nm)
Seat Slider Fasteners
11 ft-lbs (15 Nm)
Seat Base Fasteners
30 ft-lbs (41 Nm)
ELECTRICAL
ITEM
TORQUE
Battery Hold-Down Strap
Fastener
10 ft-lbs (13.5 Nm)
Voltage Regulator
Fasteners
8 ft-lbs (11 Nm)
Starter Mounting
Fasteners
7 ft-lbs (10 Nm)
ELECTRICAL
ITEM
TORQUE
Ignition Coil Retaining
Bolt
75 in-lb (9 Nm)
ECT Sensor 17 ft-lb (23 Nm)
ECU Fasteners 12 in-lbs (1.3 Nm)
Fuse Block Fasteners
8 ft-lbs (11 Nm)
Starter Connections 60 in-lbs (7 Nm)
Tail Light Fasteners
12 in-lbs (1.3 Nm)
Battery Terminal
Fasteners
6 ft-lbs (8 Nm)
GENERAL INFORMATION
1
