3.46
ENGINE
6. Turn the puller T–Handle clockwise until it contacts the
water pump shaft. Continue rotating until the remaining
portion of mechanical seal has been removed from the case.
(Figure 3-48)
7. Water Pump Install Kit (PN 5131135) is required to install
the new mechanical seal. This tool is available separately
as well as included in Crankshaft / Water Pump Seal
Installation Kit (PN 2871283).
TROUBLESHOOTING
Engine
Engine Turns Over But Fails to Start
•No fuel
• Dirt in fuel line or filter
• Fuel will not pass through fuel valve
• Fuel pump inoperative/restricted
• Tank vent plugged
• Carb starter circuit
• Engine flooded
• Low compression (high cylinder leakage)
• No spark (Spark plug fouled)
Engine Does Not Turn Over
• Dead battery
• Starter motor does not turn
• Engine seized, rusted, or mechanical failure
Engine Runs But Will Not Idle
• Restricted carburetor pilot system
• Carburetor misadjusted
• Choke not adjusted properly
• Low compression
• Crankcase breather restricted
Figure 3-48
